VA6000 Series

Ideal for USB peripherals and infotainment systems, the VA6000 Series supports the convergence and extension of symmetric high bandwidth interfaces over the simplest infrastructure

USB3.2

USB2.0

Ethernet

I2S

Frame Sync

UART

GPIO

Power

High Performance Connectivity

Zero latency, up to 6Gbps/6Gbps symmetric connectivity

Simplest Infrastructure

Leveraging low-cost unshielded channels for multi-gig bandwidth

USB Convergence

Supporting professional-grade extension of USB 3.2 or the converged interfaces of USB 2.0, Ethernet, Audio and Serial Controls.

Market Applications

VA6000 Chipsets

VS6320

USB 3.2 extension for video conferencing

USB 3.2 extension for video conferencing

Key Specs:

Converged Interfaces

USB 3.2 Gen1, USB 2.0 UART, MSIO, FrameSync, GPIO

Bandwidth

6Gbps/6Gbps

Link

100m/328ft over Cat6a

VA6000 Fully Featured

Multimedia convergence & extension for infotainment systems

Multimedia convergence & extension for infotainment systems

Key Specs:

Converged Interfaces

USB 2.0, 1Gbps Ethernet , I2S/TDM, I2C, UART

Bandwidth

2Gbps/2Gbps

Link

15m/50ft over UTP / Coax

VA6000 Extended Reach

Convergence & extension of multimedia for video conferencing

Convergence & extension of multimedia for video conferencing

Key Specs:

Converged Interfaces

USB 2.0, 100Mbps Ethernet , I2S/TDM, I2C, UART

Bandwidth

500Mbps/500Mbps

Link

100m/328ft over Cat6a

VA6003

1Gb Ethernet over UTP for in-vehicle connectivity

1Gb Ethernet over UTP for in-vehicle connectivity

Key Specs:

Converged Interfaces

1Gbps Ethernet , I2S/TDM, I2C, UART

Bandwidth

500Mbps/500Mbps

Link

15m/50ft over UTP / Coax

VA600R

Longest reach ethernet connectivity for tractor-trailers visibility

Longest reach ethernet connectivity for tractor-trailers visibility

Key Specs:

Converged Interfaces

100Mbps Ethernet , I2C, UART

Bandwidth

250Mbps/250Mbps

Link

40m/131ft over UTP / Coax / Jumper Cable

Valens USB and Power Extender

USB 2.0 & Power extension over single Cat cable

USB 2.0 & Power extension over single Cat cable

Key Specs:

Converged Interfaces

USB 2.0, Power

Bandwidth

100m/328ft over Cat6a

Link

Cat 5e, Cat6a recommended

Download

VA6000 Series Product Specs
